IGS Audio Volf
Experience precise bass control with IGS Audio Volf, a stereo audio compressor inspired by UREI 1176, perfect for both studio and live applications.
Vorteile
- 24-step, Swiss-made ELMA switches on Input, Output, and Mixer for precise control.
- Fully stepped controls on all parameters, ensuring consistent and repeatable adjustments.
- Switchable input mode between transformer-balanced or IC-balanced inputs for greater tonal flexibility.
- AMP mode, which bypasses compression, allowing the signal to pass through the amplifier with 45dB.
- Ultra-low noise discrete IGS 2520 Op-Amps in both amplification stages for pristine sound and minimal noise.
- Link option for stereo image balance, ensuring optimal stereo imaging and coherence in a mix.
- A Class A circuit, providing smooth, transparent processing ideal for professional audio environments.
- UTM Industry input and output transformers
- Linear power supply
Produktinformationen "IGS Audio Volf"
VOLF is a stereo audio compressor inspired by the legendary UREI 1176, renowned for its fast attack times and transparent compression. Designed to handle bass frequencies with precision, VOLF captures the punch and warmth of the original 1176, while offering modern stereo capabilities, making it the perfect tool for both studio and live sound applications. With its intuitive controls and robust build, VOLF ensures that your low-end dynamics are smooth and controlled, without sacrificing tonal richness.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
FET CompressorBF245A, matched quad transistorBasic Features
- All stepped controls: Yes, 24-step ELMA switches
- Sidechain High Pass Filter: 240, 180, 120, 90, 60 Hz, Off
- Input Impedance (balanced): 10 kOhm, IC/UTM Industry switchable transformers
- Output Impedance (balanced): 600 Ohm, UTM Industry transformers
- Operating Level: +4 dBu
- Max Input Level: +18 dBu
- Max Output Level: +18 dBu
- Max Gain Reduction: 30 dB
- Max Gain: 45 dB
- Noise Floor: 110 dB A
- Attack: 20 μs – 1.2 ms
- Release: 0.05 - 1.2 s
- Frequency Response: 8 Hz - 22 kHz +/- 0.2 dB
- Distortion (@ 20 Hz - 20 kHz):
- Signal to Noise Ratio: >84 dB
- THD: 0.12 %
- THD+N: 0.19 %
- Crosstalk: 80 dB
- Power Consumption: 20 Watts
- Power Supply: Internal
- Dimensions: 70 x 50 x 30 cm
- Shipping Weight: 8 kg
