Neumann EA 89 A mtThe EA 87 is designed for the U 87 Ai microphone. It has a swivel mount with a 5/8"-27 female thread, plus a thread adapter to connect to 1/2"- and 3/8" studs. For more information, please visit this products webpage
Neumann IC 5 mtMicrophone cable with double twist (double helix) braiding as shield. Diameter 5 mm, length 10 m. XLR 5 connectors.Other cable lengths are available upon request! Cable material without connectors are also available.Even if very long (Neumann) cables are used, the electroacoustic characteristics of the microphone are not affected.Only with cable lengths well over 300 m a high-frequency roll-off is noticeable. For more information, please visit this products webpage
Neumann is excited to introduce its latest innovation, the KH 120, representing the first product in the new line of Neumann Studio Monitors.
The KH 120 A studio monitor is designed for use as a near-field loudspeaker or as a rear loudspeaker in larger multi-channel systems. The KH 120 A represents the latest in acoustic and electronic simulation and measurement technologies to ensure the most accurate sound reproduction possible. It has a Mathematically Modeled Dispersion waveguide (MMD (TM), flexible acoustical controls, analog class-AB amplifiers, a large headroom analog input and an extensive mounting hardware range. All of this provides the user with the maximum versatility over a wide variety of acoustic conditions, source equipment, and physical locations.
The KH 120 is perfect for tracking, mixing and mastering in music, broadcast, project and post-production studios.
Features
Product Feature Benefit to the Customer
Powerful titanium fabric dome
Low-distortion high-frequency reproduction
Elliptical Mathematically Modelled Dispersion™
(MMD™) waveguide
Smoother off-axis response,
More forgiving of diverse acoustical environments
Composite sandwich cone
Damping of break-up modes
Long throw bass driver
Low distortions at high sound levels
Two-color + dimmable Neumann logo
Displays operation status and activation of the extensive protection system
Robust metal grille
Protects against mechanical damage
Large front panel ports
Reduced bass compression and easier to mount in tight spaces such as OB vans
Compact aluminum cabinet
(magnetically shielded)
Minimizes resonances, better heat dissipation, long life
Wide horizontal dispersion
Freedom of movement across the mixing console
Narrow vertical dispersion
Reduces reflections off the mixing console
One-piece front panel with no discontinuities
Reduced diffraction and smoother frequency response
Powerful analog amplifiers with large headroom
Improved transient response
Production consistency
Any KH 120 is “pair-matched” to any other KH 120
4-position bass, low-mid and treble acoustical controls
More control in diverse acoustical environments
Wide range input gain and output level controls
Easier interfacing with signal sources
New mounting hardware options
More flexibility in mounting cabinets in more diverse locations
Display dimmer
For low lighting level conditions or behind the screen applications
Ground lift
Reduced noise in electrically noisy environments and over-comes ground loops
Universal switched-mode power supply
(100 … 240 V)
One version works in any country and robust to poor quality mains supply
Separate woofer and tweeter electronic peak limiters and thermal-protection circuitry
High reliability
Technical Data
Acoustics
-3 dB free field frequency response 52 Hz … 21 kHz, ± 3 dB
Pass band free field frequency response 54 Hz … 20 kHz, ± 2 dB
Self-generated noise
(with input gain set to 100 dB for 0 dBu) <20 dB(A) at 10 cm
Sine wave output with a THD < 0.5 % at 1 m 100 Hz @ 95 dB SPL
Max. SPL In half space at 3% THD at 1m 111.1 dB SPL
(averaged between 100 Hz and 6 kHz)
Max SPL with pink noise in a typical installation 92 dB(C) at 2.3 m, (full range)
94 dB(C) at 2.3 m (with KH 810)
Electronics
Woofer amplifier, cont.(peak) output power* 50 W (80 W)
Tweeter amplifier, cont.(peak) outputpower* 50 W (80 W)
Controller design Analog, active
Crossover Frequency 2.0 kHz
Crossover Slope (dB/oct.) 24, 4th order
Equalization - Bass 0, -2.5, -5, -7.5 dB
Equalization - Mid 0, -1.5, -3, -4.5 dB
Equalization - High +1, 0, -1, -2 dB
Protection circuitry Limiter: low, high
Infrasonic filter frequency; slope 30 Hz; 6 dB/oct.
Analog Input
Impedance, electrically balanced
10k Ohms in position 94/108 dB SPL at 1 m
20k Ohms in position 100/114 dB SPL at 1 m
Input gain control (sensitivity) 0 dBu to -15 dBu
Output level control 94, 100, 108, 114 dB SPL
CMRR >56 dB @ 15 kHz
Maximum input level 24 dBu
Displays and Mains Power
Displays and indicators - power on Neumann logo “White”
Displays and indicators - limit/clip Neumann logo “Red”
Mains Power Supply, voltage; frequency 100-240 V~; 50/60 Hz
Power consumption – Idle 20 W
Power consumption – Full output AC 200 W
Mechanics
Cabinet surface finish, color: custom Painted aluminium, Anthracite (RAL 7021)
Operating conditions +10° C to +40° C (+50° F to +104° F),
<90% RH, non-condensing
Transport/storage conditions −25° C to +70° C (−13° F to 158° F),
<90% RH, non-condensing
Drivers Magnetically shielded
Woofer 130 mm (5.25”)
Tweeter 25 mm (1”)
Mounting points 2 x M8 on rear panel
Height x width x depth, mm (inches) 277 x 182 x 220 mm (10 7/8” x 7 1/8” x 8 5/8”)
Internal net volume / external volume 6.5 liters / 9.7 liters
Weight 6.2 kg (13.7 lbs)
